In a nutshell
Weight: 11 kg in size M (without pedals)
Frame material: Carbon
Type: Full suspension
Wheel size: 29"
Fork travel: 120 mm
Shock travel:120 mm
Drive train: 1x12
Brakes: hydraulic disc
Seat post: Telescopic (electronic)
5-year warranty on the frame/2 years for the components
ACCESSORIES INCLUDED
Your MTB comes with:
- SRAM AXS charger and 4 batteries
- 2 x 120 ml bottles of Hutchinson tyre sealant
- 2 tubeless valves
- Torque wrench
- Top tube protector
- Front/rear lights
- Assembly instructions
- Brake calliper spacers
Wheels
Zipp 1 Zero Hitop SW, 29"
Internal width: 30 mm/front, rear
Number of spokes:24 spokes/front, rear
Disc mountCenter Lock
Freehub body: Sram XD
Axle types: Thru axles, 15x110 mm at the front and 12x148 mm at the rear
Tubeless Ready:Yes
Equipped with watertight rim tape: Yes
Weight: 1375 g
Frame
Composition: Carbon
Travel:120 mm front/rear
Rear axle:12x148 mm
Type of axle: Thru axle
Bottom bracket:PF92
Seat tube diameter: 31.6 Mm
Bottle cage mount:yes (2 bottles)
Suspension
Fork: RockShox SID Ultimate Red Flight Attendant
Travel: 120 mm
Dampers: 35 mm
Axle: thru axle
Format: 15 x 110 mm
Shock: RockShox SIDLuxe Ultimate Black FA
(with specific internal adjustment for the Race 940S)
Size:190x45 mm
Weight
S: 10.9 kg
M: 11 kg
L: 11.1 kg
XL: 11.3 kg
Net weight without pedals
Tyres
Vittoria
Mezcal Race 29" x 2.25"
Tubeless Ready: Yes
Brakes
Hydraulic disc brakes SRAM Motive Ultimate
Number of pistons: 4
Front disc: 180 mm
Rear disc: 160 mm
Disc mount: Center Lock
Riding position
Handlebar/Stem: Magnus HX.01
Material: Carbon
Width: 760 mm
Angle: -30°
Stem: 85 mm
Material: Carbon
Backsweep: 7°
Upsweep: 5°
Grips: Rockrider silicone
Width: 130 mm
Diameter: 33 mm
Pedals
Rockrider FLAT EVO platform pedals
Material: resin
Drivetrain
SRAM AXS
Single chainring: SRAM XX SL EAGLE
36 teeth
MaterialAluminium
Cranks: SRAM XX EAGLE (power sensor)
170 mm (sizes S/M) and 175 mm (sizes L/XL)
Material:Carbon
Rear derailleur:SRAM XX SL EAGLE T-TYPE AXS
12 speeds
Cassette:SRAM XS 1299 EAGLE : SRAM XX SL
10-52 teeth
Chain: SRAM XX SL EAGLE : 118 links
/ Seat post
Saddle: FIZIK VENTO ARGO X3
Seat post: SRAM Reverb AXS 31.6 B1
(electronic dropper seat post)
Material:Aluminium
Diameter: 31.6 mm
Travel: 100 mm (size S), 125 mm (size M/L/XL)
